Channel details and members

Channel details is a screen with everything about one channel: its profile and settings, its members, its pinned messages, and the photos, videos and files shared in it. ChannelDetails renders it for the channel of the ChannelDetailsContextProvider around it. This page covers what users can do there and what each part calls in the state layer. Where the screen goes in your navigator is on Channel UI.

What users get

The user taps the avatar in the header of the "Design" channel, and the app opens its details screen. The header reads "Group Info", with a back button and an Edit button. Below it are:

• The profile: the channel's avatar and name, and how many members it has and how many are online. A mute icon follows the name while the channel is muted.
• Pinned Messages, Photos & Videos and Files, three rows that each open a full-screen list. Pinned Messages has a search field once the channel has pinned messages. Photos & Videos is a grid, and tapping a photo or video opens it in the image gallery. Files lists the files and audio shared in the channel, under a header per month, and tapping one opens it.
• The members: "8 members", with an Add button and the first five members. Each shows the member's role (Owner, Admin or Moderator) and whether they're online or when they were last seen. View all opens the full list, with a search field. Tapping a member opens a sheet with Mute User, Block User and Remove User.
• The actions: a Mute Group switch, Leave Group, and Delete Group when the user created the channel.

Edit opens a form that changes the channel's name and image. Add opens a search for users, where the user selects the users to add. Users who are already members show "Already a member" and can't be selected.

A direct message channel is different. The header reads "Contact Info" and has no Edit button. The profile shows "Online" while the other person is online, and the screen has no members section. The actions are a Mute Chat switch, a Mute User switch, Block User, Leave Chat, and Delete Chat when the user created the channel.

Leaving, deleting, blocking and removing a member ask the user to confirm first. Each action confirms its result with a notification, such as "1 member removed" or "Channel name updated".

How it works across the layers

State: what each part calls

Every part works on the channel from ChannelDetailsContextProvider, through the state layer:

The saved name and image come back in the channel's data as custom.name and custom.image. An empty name unsets it, so the channel falls back to its members' names.

The lists behind View all, Add, Pinned Messages, Photos & Videos and Files come from search sources. Each list creates its source when it opens, queries the first 25 items, and loads the next page as the user scrolls. The sources are a snapshot: they don't change as events arrive, so a message pinned while the list is open shows the next time it opens. The member list is the exception. When the channel's member count changes while no search text is entered, it queries its first page again. Search sources explains how they load.

The state doesn't change before the server answers. The channel's data, its members and the user's mute and block lists change when the response or the server's event arrives. The mute switches are the one place the UI runs ahead: a switch flips at once, and flips back if the request fails. What channels and threads hold lists the fields and the events that change them.

The actions and the member sheet are action items, the same kind as the channel list's row actions. Actions lists them with their ids.

UI: the screen

ChannelDetails renders, from top to bottom, ChannelDetailsNavHeader, ChannelDetailsProfile, ChannelDetailsNavigationSection, ChannelDetailsMemberSection and ChannelDetailsActionsSection, in a ScrollView. Each is an override key. It reads the channel with useChannelDetailsContext(), so render it inside a ChannelDetailsContextProvider. It doesn't need a Channel around it.

The screen doesn't navigate on its own. Its back button calls onBack. Edit, Add, View all and the three navigation rows open their forms and lists in a React Native Modal on top of the screen. The three rows open full screen, and the others open as a page sheet on iOS. closeModals() from useChannelDetailsContext() closes them all. The member sheet, and the sheet that picks a new image in the Edit form, open as bottom sheets. Picking an image uses the image picker and camera handlers of stream-chat-react-native or stream-chat-expo.

Three things leave the screen, and each needs your app:

• Leave, delete and block call onChannelDismiss on ChannelDetailsActionsSection once they succeed, so your app can close the channel's screens.
• Pinned messages aren't pressable. To jump to one, replace the PinnedMessageItem key with a row that navigates, as Pinned messages shows.
• A member has no Send Direct Message action. Member actions adds one.

ChannelDetails publishes the notifications of its actions to a notification list of its own, and each modal has its own too. See Displaying notifications.

Turning it on or off

Channel details is off until your app opens it: the SDK has no button that navigates to it. Give it a screen of your own, wrap ChannelDetails in ChannelDetailsContextProvider with the channel, and navigate to the screen from your channel header. Channel UI has the screen for React Navigation.

Who sees which action depends on the channel and on the user's capabilities in it, which the server derives from their roles and the channel type's permissions:

A direct message channel here is one with exactly one member besides the current user. Leave and Delete check no capability, so a user without leave-channel or delete-channel sees them and gets an error notification. Change capabilities on the server; see Permissions reference.

Customizing

Choosing the rows

ChannelDetailsNavigationSection takes getNavigationItems, which receives the default rows, with the sections pinned-messages, photos-and-videos and files, and returns the rows to show. ChannelDetails renders the section without props, so pass the function through an override. This screen has no Files row:

import type { Channel as StreamChannel } from "stream-chat";
import {
  ChannelDetails,
  ChannelDetailsContextProvider,
  ChannelDetailsNavigationSection,
  WithComponents,
} from "stream-chat-react-native";
import type {
  ChannelDetailsNavigationSectionProps,
  ComponentOverrides,
  GetChannelDetailsNavigationItems,
} from "stream-chat-react-native";

const getNavigationItems: GetChannelDetailsNavigationItems = ({
  defaultItems,
}) => defaultItems.filter(({ section }) => section !== "files");

const NavigationSection = (props: ChannelDetailsNavigationSectionProps) => (
  <ChannelDetailsNavigationSection
    {...props}
    getNavigationItems={getNavigationItems}
  />
);

// Declared outside the component, so WithComponents gets the same object on every render.
const overrides: ComponentOverrides = {
  ChannelDetailsNavigationSection: NavigationSection,
};

export const ChannelDetailsScreen = ({
  channel,
  onBack,
}: {
  channel: StreamChannel;
  onBack: () => void;
}) => (
  <ChannelDetailsContextProvider channel={channel}>
    <WithComponents overrides={overrides}>
      <ChannelDetails onBack={onBack} />
    </WithComponents>
  </ChannelDetailsContextProvider>
);

A row with an onPress calls it instead of opening its modal, which is how a row opens a screen of your own. The Custom navigation items UI cookbook adds rows.

Screens instead of modals

Each modal can be swapped for a screen in your navigator:

• ChannelDetailsEditButton and ChannelAddMembersButton take onPress, which replaces opening the edit or add form.
• ChannelDetailsMemberSection takes onViewAllMembersPress, which replaces opening the member list.
• getNavigationItems sets onPress on a row, as above.

The forms and lists are exported, so your screens render them: ChannelEditDetailsForm, ChannelAddMembersForm, ChannelMemberList, PinnedMessageList, MediaList and FileAttachmentList. Wrap each screen in ChannelDetailsContextProvider with the same channel. The Custom navigation UI cookbook does this for every modal.

Uploading the channel image to your own storage

By default, Edit uploads a new channel image with client.uploadImage(), to Stream's CDN. ChannelEditDetailsForm takes doFileUploadRequest: a function that gets the picked file and returns { file }, the URL to save. ChannelDetailsEditButton renders the form from the ChannelEditDetailsForm key, so set it there:

import { ChannelEditDetailsForm } from "stream-chat-react-native";
import type {
  ChannelEditDetailsFormProps,
  ComponentOverrides,
  GlobalFileUploadRequest,
} from "stream-chat-react-native";

const uploadToOwnStorage: GlobalFileUploadRequest = async (file) => {
  const body = new FormData();
  // React Native's FormData sends a local file given as { uri, name, type }.
  body.append("file", {
    name: file.name ?? "channel-image.jpg",
    type: file.type,
    uri: file.uri,
  });
  const response = await fetch("https://example.com/api/uploads", {
    body,
    method: "POST",
  });
  const { url } = (await response.json()) as { url: string };
  return { file: url };
};

const EditForm = (props: ChannelEditDetailsFormProps) => (
  <ChannelEditDetailsForm {...props} doFileUploadRequest={uploadToOwnStorage} />
);

// Pass these to WithComponents around ChannelDetails.
export const editFormOverrides: ComponentOverrides = {
  ChannelEditDetailsForm: EditForm,
};

compressImageQuality, from 0 to 1, compresses the picked image before it's uploaded.

Changing the actions

The actions section and the member sheet take functions that receive the default items and return the items to show. Channel actions shows how to pass one to channel details, and Member actions does the same for the member sheet. The UI cookbooks Custom channel actions and Custom member actions build complete examples.

Member roles

ChannelMemberItem takes getMemberRoles, which receives the default roles and returns the roles to show. By default, the creator of the channel is Owner, a user whose role is admin is Admin, and a member whose channel role is channel_moderator is Moderator. The Custom member roles UI cookbook shows other roles.

Adding members with history hidden

The Add form adds the selected users with Channel.addMembers({ members: userIds }), so they see the channel's whole history. To hide it, replace the form's header so that it adds them with the history options; see History visibility for new members.

Reference

• ChannelDetails: the ChannelDetails props and its sections.
• Channel details lists: the member list, the add form, and the pinned messages, media and files lists.
• Channel details contexts: ChannelDetailsContextProvider and the contexts of the forms and lists.
• Channel details hooks: the hooks the sections use, such as useMemberRoles and useCanAddMembersToChannel.
• Channel and channel state: addMembers, removeMembers, updatePartial and the other channel methods.
