Set Up Your Angular Environment
The easiest way to build a Stream Chat Angular application from this tutorial is to create a new project using Angular CLI. Angular CLI builds an Angular boilerplate application that you can run locally with just a few simple commands.
Before you start: Make sure you've installed Angular CLI globally.
The SDK supports Angular versions from 15-18, you can complete the tutorial using any version. Angular 17-18 code snippets use standalone components, other versions are using module-based components.
Create a new application with Angular CLI:
1ng new chat-example --routing false --style scss --ssr false
1ng new chat-example --routing false --style scss
Note You can use other style language if you wish.
Install the necessary dependencies:
1234npm install stream-chat-angular ngx-float-ui@18 # or yarn add stream-chat-angular ngx-float-ui@18
1234npm install stream-chat-angular ngx-float-ui@17 # or yarn add stream-chat-angular ngx-float-ui@17
1234npm install stream-chat-angular ngx-float-ui@16 # or yarn add stream-chat-angular ngx-float-ui@16
1234npm install stream-chat-angular @ngx-translate/core@14 ngx-float-ui@15 # or yarn add stream-chat-angular @ngx-translate/core@14 ngx-float-ui@15
Create a WhatsApp or Facebook Messenger Style Chat App
Stream's Angular Chat messaging SDK component library includes everything you need to build a fully functioning chat experience, supporting rich messages, reactions, image uploads, and more. This library was designed to enable you to get an application up and running quickly and efficiently while supporting customization for complex use cases.
We’ve included a few Stream Angular Chat examples to show you what’s possible:
- Basic chat components cxample
- Customizable UI components example
Build a Basic Chat App with Stream’s Core Angular Components
In the sample below, you’ll find the following basic chat components of the Angular library:
- ChannelList
- Channel
- ChannelHeader
- MessageInput
- MessageList
- Thread
To get started:
- Import the modules
Replace the src/app/app.config.ts
file with the following:
12345678910import { ApplicationConfig, importProvidersFrom } from '@angular/core'; import { TranslateModule } from '@ngx-translate/core'; export const appConfig: ApplicationConfig = { providers: [ // For Angular 18, you can enable the new change detection mode: // provideZoneChangeDetection({ eventCoalescing: true }), importProvidersFrom(TranslateModule.forRoot()) ], };
Add other modules to your AppComponent
:
123456789101112import { Component } from '@angular/core'; import { TranslateModule } from '@ngx-translate/core'; import { StreamAutocompleteTextareaModule, StreamChatModule } from 'stream-chat-angular'; @Component({ selector: 'app-root', standalone: true, imports: [TranslateModule, StreamAutocompleteTextareaModule, StreamChatModule], templateUrl: './app.component.html', styleUrls: ['./app.component.scss'], }) export class AppComponent {}
Replace the content of your AppModule
with the following code:
1234567891011121314import { NgModule } from '@angular/core'; import { BrowserModule } from '@angular/platform-browser'; import { TranslateModule } from '@ngx-translate/core'; import { AppComponent } from './app.component'; import { StreamChatModule, StreamAutocompleteTextareaModule } from 'stream-chat-angular'; @NgModule({ declarations: [AppComponent], imports: [BrowserModule, TranslateModule.forRoot(), StreamAutocompleteTextareaModule, StreamChatModule], providers: [], bootstrap: [AppComponent], }) export class AppModule {}
This will import the TranslateModule
and the StreamChatModule
.
If you already use ngx-translate in your application, follow our translation guide to set up translation.
In an effort to keep our bundle size small in the long run our SDK uses an architecture where integrators can decide to opt-out of certain costly (in terms of bundle size) features, this decision happens at module import, in the above example we chose what type of textarea component we want to use (StreamAutocompleteTextareaModule
). You can find more information about this topic in our opt-in architecture guide.
- Init the chat application
Replace the content of your app.component.ts
with the following code:
12345678910111213141516171819202122232425262728293031323334353637383940414243import { Component, OnInit } from '@angular/core'; import { TranslateModule } from '@ngx-translate/core'; import { ChatClientService, ChannelService, StreamI18nService, StreamAutocompleteTextareaModule, StreamChatModule, } from 'stream-chat-angular'; @Component({ selector: 'app-root', standalone: true, imports: [TranslateModule, StreamAutocompleteTextareaModule, StreamChatModule], templateUrl: './app.component.html', styleUrls: ['./app.component.scss'], }) export class AppComponent implements OnInit { constructor( private chatService: ChatClientService, private channelService: ChannelService, private streamI18nService: StreamI18nService, ) { const apiKey = 'REPLACE_WITH_API_KEY'; const userId = 'REPLACE_WITH_USER_ID'; const userToken = 'REPLACE_WITH_USER_TOKEN'; this.chatService.init(apiKey, userId, userToken); this.streamI18nService.setTranslation(); } async ngOnInit() { const channel = this.chatService.chatClient.channel('messaging', 'talking-about-angular', { // add as many custom fields as you'd like image: 'https://upload.wikimedia.org/wikipedia/commons/thumb/c/cf/Angular_full_color_logo.svg/2048px-Angular_full_color_logo.svg.png', name: 'Talking about Angular', }); await channel.create(); this.channelService.init({ type: 'messaging', id: { $eq: 'talking-about-angular' }, }); } }
12345678910111213141516171819202122232425262728293031323334import { Component, OnInit } from '@angular/core'; import { ChatClientService, ChannelService, StreamI18nService } from 'stream-chat-angular'; @Component({ selector: 'app-root', templateUrl: './app.component.html', styleUrls: ['./app.component.scss'], }) export class AppComponent implements OnInit { constructor( private chatService: ChatClientService, private channelService: ChannelService, private streamI18nService: StreamI18nService, ) { const apiKey = 'REPLACE_WITH_API_KEY'; const userId = 'REPLACE_WITH_USER_ID'; const userToken = 'REPLACE_WITH_USER_TOKEN'; this.chatService.init(apiKey, userId, userToken); this.streamI18nService.setTranslation(); } async ngOnInit() { const channel = this.chatService.chatClient.channel('messaging', 'talking-about-angular', { // add as many custom fields as you'd like image: 'https://upload.wikimedia.org/wikipedia/commons/thumb/c/cf/Angular_full_color_logo.svg/2048px-Angular_full_color_logo.svg.png', name: 'Talking about Angular', }); await channel.create(); this.channelService.init({ type: 'messaging', id: { $eq: 'talking-about-angular' }, }); } }
First, we connect a user to the chat client. Further information about connecting users is available in our platform documentation.
Next, we create a channel (if doesn't exist) to test with. You can read more about channel creation in our platform documentation.
Lastly, we provide a filter condition for loading channels. If you want to know more about filtering channels, our platform documentation got you covered.
We also set up the translation for the application. If you want to customize it, check out our translation guide.
- Create the chat UI
Replace the content of the app.component.html
with the following code:
12345678910111213<div id="root"> <stream-channel-list></stream-channel-list> <stream-channel> <stream-channel-header></stream-channel-header> <stream-message-list></stream-message-list> <stream-notification-list></stream-notification-list> <stream-message-input></stream-message-input> <stream-thread name="thread"> <stream-message-list mode="thread"></stream-message-list> <stream-message-input mode="thread"></stream-message-input> </stream-thread> </stream-channel> </div>
- Import CSS
Add the following code to your root stylesheet (styles.scss
if you are using SCSS):
123456789101112131415161718192021222324252627@import 'stream-chat-angular/src/assets/styles/scss/index.scss'; html { height: 100%; } body { margin: 0; height: 100%; } #root { display: flex; height: 100%; stream-channel-list { width: 30%; } stream-channel { width: 100%; } stream-thread { width: 45%; } }
Important note If you are using CSS stylesheets, you should add the following import instead:
1@import 'stream-chat-angular/src/assets/styles/css/index.css';
The SDK lets you create your own responsive layout, the code above contains a minimal setup where the channel list is displayed next to the channel component.
- Modify
tsconfig.json
Add the following option to the compilerOptions
in tsconfig.json
file:
1"allowSyntheticDefaultImports": true
We need to enable synthetic default imports becuase the stream-chat
library uses them.
- Start the application
Run the following command:
1npm start
⚠️ If you run into SCSS issues, expand the section below and follow the steps.
If you run into SCSS issues related to icons, you should extend the stylesheet import like this:
1234@use "stream-chat-angular/src/assets/styles/scss/variables" with ( $assetsPath: "../node_modules/stream-chat-angular/src/assets/assets" ); @import "stream-chat-angular/src/assets/styles/scss/index.scss";
You can read more about the underlying issue on Angular's GitHub.
Once you have the app running, you’ll notice the following out-of-the-box features:
- User online presence
- Message status indicators (sending, received)
- User role configuration
- Message read indicators
- Message reactions
- URL previews (send a link to see it in action, for example, https://getstream.io/)
- GIFs (type
/giphy
in the message input) - Threads
- File uploads and previews
- AI-powered spam and profanity moderation
Creating Your Own UI Components
If the built-in theming capabilities are not enough for you, you can create your own custom components.
In the below example, you’ll create custom ChannelPreview
and Message
components.
- Create the
Message
component
Run the following command:
1ng g c message --inline-style --inline-template --standalone
1ng g c message --inline-style --inline-template
- Implement the
Message
component
Replace the content of the message.component.ts
with the following code:
123456789101112131415161718import { Component, Input } from '@angular/core'; import { StreamMessage } from 'stream-chat-angular'; @Component({ selector: 'app-message', standalone: true, imports: [], template: ` <div> <b>{{ message?.user?.name }}</b> {{ message?.text }} </div> `, styles: ['b {margin-right: 4px}'], }) export class MessageComponent { @Input() message: StreamMessage | undefined; constructor() {} }
12345678910111213141516import { Component, Input } from '@angular/core'; import { StreamMessage } from 'stream-chat-angular'; @Component({ selector: 'app-message', template: ` <div> <b>{{ message?.user?.name }}</b> {{ message?.text }} </div> `, styles: ['b {margin-right: 4px}'], }) export class MessageComponent { @Input() message: StreamMessage | undefined; constructor() {} }
- Use the custom message component
Provide the customMessageTemplate
to the CustomTemplatesService
:
In the HTML of your AppComponent
:
1234567891011121314151617<div id="root"> <stream-channel-list></stream-channel-list> <stream-channel> <stream-channel-header></stream-channel-header> <stream-message-list></stream-message-list> <stream-notification-list></stream-notification-list> <stream-message-input></stream-message-input> <stream-thread name="thread"> <stream-message-list mode="thread"></stream-message-list> <stream-message-input mode="thread"></stream-message-input> </stream-thread> </stream-channel> </div> <ng-template #customMessageTemplate let-message="message"> <app-message [message]="message"></app-message> </ng-template>
In the component class of your AppComponent
12345678910111213141516171819202122232425262728293031323334353637383940414243444546474849505152535455import { AfterViewInit, Component, OnInit, TemplateRef, ViewChild } from '@angular/core'; import { TranslateModule } from '@ngx-translate/core'; import { ChatClientService, ChannelService, StreamI18nService, StreamAutocompleteTextareaModule, StreamChatModule, CustomTemplatesService, MessageContext, } from 'stream-chat-angular'; import { MessageComponent } from './message/message.component'; @Component({ selector: 'app-root', standalone: true, templateUrl: './app.component.html', styleUrls: ['./app.component.scss'], imports: [TranslateModule, StreamAutocompleteTextareaModule, StreamChatModule, MessageComponent], }) export class AppComponent implements OnInit, AfterViewInit { // Create a reference to your custom template @ViewChild('customMessageTemplate') messageTemplate!: TemplateRef<MessageContext>; constructor( private chatService: ChatClientService, private channelService: ChannelService, private streamI18nService: StreamI18nService, private customTemplatesService: CustomTemplatesService, // Import the CustomTemplatesService ) { const apiKey = 'REPLACE_WITH_API_KEY'; const userId = 'REPLACE_WITH_USER_ID'; const userToken = 'REPLACE_WITH_USER_TOKEN'; this.chatService.init(apiKey, userId, userToken); this.streamI18nService.setTranslation(); } async ngOnInit() { const channel = this.chatService.chatClient.channel('messaging', 'talking-about-angular', { // add as many custom fields as you'd like image: 'https://upload.wikimedia.org/wikipedia/commons/thumb/c/cf/Angular_full_color_logo.svg/2048px-Angular_full_color_logo.svg.png', name: 'Talking about Angular', }); await channel.create(); this.channelService.init({ type: 'messaging', id: { $eq: 'talking-about-angular' }, }); } ngAfterViewInit(): void { // Register your template this.customTemplatesService.messageTemplate$.next(this.messageTemplate); } }
12345678910111213141516171819202122232425262728293031323334353637383940414243import { AfterViewInit, Component, OnInit, TemplateRef, ViewChild } from '@angular/core'; import { ChatClientService, ChannelService, StreamI18nService, MessageContext, CustomTemplatesService } from 'stream-chat-angular'; @Component({ selector: 'app-root', templateUrl: './app.component.html', styleUrls: ['./app.component.scss'], }) export class AppComponent implements OnInit, AfterViewInit { // Create a reference to your custom template @ViewChild('customMessageTemplate') messageTemplate!: TemplateRef<MessageContext>; constructor( private chatService: ChatClientService, private channelService: ChannelService, private streamI18nService: StreamI18nService, private customTemplatesService: CustomTemplatesService, // Import the CustomTemplatesService ) { const apiKey = 'REPLACE_WITH_API_KEY'; const userId = 'REPLACE_WITH_USER_ID'; const userToken = 'REPLACE_WITH_USER_TOKEN'; this.chatService.init(apiKey, userId, userToken); this.streamI18nService.setTranslation(); } async ngOnInit() { const channel = this.chatService.chatClient.channel('messaging', 'talking-about-angular', { // add as many custom fields as you'd like image: 'https://upload.wikimedia.org/wikipedia/commons/thumb/c/cf/Angular_full_color_logo.svg/2048px-Angular_full_color_logo.svg.png', name: 'Talking about Angular', }); await channel.create(); this.channelService.init({ type: 'messaging', id: { $eq: 'talking-about-angular' }, }); } ngAfterViewInit(): void { // Register your template this.customTemplatesService.messageTemplate$.next(this.messageTemplate); } }
- Create the
ChannelPreview
component
Run the following command:
1ng g c channel-preview --inline-style --inline-template --standalone
1ng g c channel-preview --inline-style --inline-template
- Implement the
ChannelPreview
component
Replace the content of the channel-preview.component.ts
with the following code:
12345678910111213141516171819202122232425262728293031323334import { Component, Input, OnChanges } from '@angular/core'; import { Channel } from 'stream-chat'; import { ChannelService, DefaultStreamChatGenerics } from 'stream-chat-angular'; @Component({ selector: 'app-channel-preview', standalone: true, imports: [], template: ` <div class="container" (click)="setAsActiveChannel()"> <div>{{ channel?.data?.name || 'Unnamed Channel' }}</div> <div class="preview">{{ messagePreview }}</div> </div> `, styles: ['.container {margin: 12px}', '.preview {font-size: 14px}'], }) export class ChannelPreviewComponent implements OnChanges { @Input() channel: Channel<DefaultStreamChatGenerics> | undefined; messagePreview: string | undefined; constructor(private channelService: ChannelService) {} ngOnChanges(): void { const messages = this?.channel?.state?.messages; if (!messages) { return; } this.messagePreview = messages[messages.length - 1].text?.slice(0, 30); } setAsActiveChannel() { void this.channelService.setAsActiveChannel(this.channel!); } }
1234567891011121314151617181920212223242526272829303132import { Component, Input, OnChanges } from '@angular/core'; import { Channel } from 'stream-chat'; import { ChannelService, DefaultStreamChatGenerics } from 'stream-chat-angular'; @Component({ selector: 'app-channel-preview', template: ` <div class="container" (click)="setAsActiveChannel()"> <div>{{ channel?.data?.name || 'Unnamed Channel' }}</div> <div class="preview">{{ messagePreview }}</div> </div> `, styles: ['.container {margin: 12px}', '.preview {font-size: 14px}'], }) export class ChannelPreviewComponent implements OnChanges { @Input() channel: Channel<DefaultStreamChatGenerics> | undefined; messagePreview: string | undefined; constructor(private channelService: ChannelService) {} ngOnChanges(): void { const messages = this?.channel?.state?.messages; if (!messages) { return; } this.messagePreview = messages[messages.length - 1].text?.slice(0, 30); } setAsActiveChannel() { void this.channelService.setAsActiveChannel(this.channel!); } }
- Use the custom channel preview component
Provide the customChannelPreviewtemplate
to the CustomTemplatesService
:
In the HTML of your AppComponent
123456789101112131415161718192021<div id="root"> <stream-channel-list></stream-channel-list> <stream-channel> <stream-channel-header></stream-channel-header> <stream-message-list></stream-message-list> <stream-notification-list></stream-notification-list> <stream-message-input></stream-message-input> <stream-thread name="thread"> <stream-message-list mode="thread"></stream-message-list> <stream-message-input mode="thread"></stream-message-input> </stream-thread> </stream-channel> </div> <ng-template #customMessageTemplate let-message="message"> <app-message [message]="message"></app-message> </ng-template> <ng-template #customChannelPreviewTemplate let-channel="channel"> <app-channel-preview [channel]="channel"></app-channel-preview> </ng-template>
In the component class of your AppComponent
123456789101112131415161718192021222324252627282930313233343536373839404142434445464748495051525354555657import { AfterViewInit, Component, OnInit, TemplateRef, ViewChild } from '@angular/core'; import { TranslateModule } from '@ngx-translate/core'; import { ChatClientService, ChannelService, StreamI18nService, StreamAutocompleteTextareaModule, StreamChatModule, CustomTemplatesService, MessageContext, ChannelPreviewContext, } from 'stream-chat-angular'; import { MessageComponent } from './message/message.component'; import { ChannelPreviewComponent } from './channel-preview/channel-preview.component'; @Component({ selector: 'app-root', standalone: true, templateUrl: './app.component.html', styleUrls: ['./app.component.scss'], imports: [TranslateModule, StreamAutocompleteTextareaModule, StreamChatModule, MessageComponent, ChannelPreviewComponent], }) export class AppComponent implements OnInit, AfterViewInit { @ViewChild('customMessageTemplate') messageTemplate!: TemplateRef<MessageContext>; @ViewChild('customChannelPreviewTemplate') channelPreviewTemplate!: TemplateRef<ChannelPreviewContext>; constructor( private chatService: ChatClientService, private channelService: ChannelService, private streamI18nService: StreamI18nService, private customTemplatesService: CustomTemplatesService, ) { const apiKey = 'REPLACE_WITH_API_KEY'; const userId = 'REPLACE_WITH_USER_ID'; const userToken = 'REPLACE_WITH_USER_TOKEN'; this.chatService.init(apiKey, userId, userToken); this.streamI18nService.setTranslation(); } async ngOnInit() { const channel = this.chatService.chatClient.channel('messaging', 'talking-about-angular', { // add as many custom fields as you'd like image: 'https://upload.wikimedia.org/wikipedia/commons/thumb/c/cf/Angular_full_color_logo.svg/2048px-Angular_full_color_logo.svg.png', name: 'Talking about Angular', }); await channel.create(); this.channelService.init({ type: 'messaging', id: { $eq: 'talking-about-angular' }, }); } ngAfterViewInit(): void { this.customTemplatesService.messageTemplate$.next(this.messageTemplate); this.customTemplatesService.channelPreviewTemplate$.next(this.channelPreviewTemplate); } }
1234567891011121314151617181920212223242526272829303132333435363738394041424344454647484950import { AfterViewInit, Component, OnInit, TemplateRef, ViewChild } from '@angular/core'; import { ChatClientService, ChannelService, StreamI18nService, MessageContext, CustomTemplatesService, ChannelPreviewContext, } from 'stream-chat-angular'; @Component({ selector: 'app-root', templateUrl: './app.component.html', styleUrls: ['./app.component.scss'], }) export class AppComponent implements OnInit, AfterViewInit { @ViewChild('customMessageTemplate') messageTemplate!: TemplateRef<MessageContext>; @ViewChild('customChannelPreviewTemplate') channelPreviewTemplate!: TemplateRef<ChannelPreviewContext>; constructor( private chatService: ChatClientService, private channelService: ChannelService, private streamI18nService: StreamI18nService, private customTemplatesService: CustomTemplatesService, ) { const apiKey = 'REPLACE_WITH_API_KEY'; const userId = 'REPLACE_WITH_USER_ID'; const userToken = 'REPLACE_WITH_USER_TOKEN'; this.chatService.init(apiKey, userId, userToken); this.streamI18nService.setTranslation(); } async ngOnInit() { const channel = this.chatService.chatClient.channel('messaging', 'talking-about-angular', { // add as many custom fields as you'd like image: 'https://upload.wikimedia.org/wikipedia/commons/thumb/c/cf/Angular_full_color_logo.svg/2048px-Angular_full_color_logo.svg.png', name: 'Talking about Angular', }); await channel.create(); this.channelService.init({ type: 'messaging', id: { $eq: 'talking-about-angular' }, }); } ngAfterViewInit(): void { this.customTemplatesService.messageTemplate$.next(this.messageTemplate); this.customTemplatesService.channelPreviewTemplate$.next(this.channelPreviewTemplate); } }
References
To learn more about the Angular SDK, check our SDK documentation and guides:
Final Thoughts
In this chat app tutorial we built a fully functioning Angular messaging app with our Angular SDK component library. We also showed how easy it is to customize the behavior and the style of the Angular chat app components with minimal code changes.
Both the chat SDK for Angular and the API have plenty more features available to support more advanced use-cases such as push notifications, content moderation, rich messages and more. Please check out our Android tutorial too. If you want some inspiration for your app, download our free chat interface UI kit.
