React Native: How To Build Bidirectional Infinite Scroll
There have been many discussions on Stack Overflow and GitHub around implementing infinite scroll using React Native, on top of
SectionList. I've found that there aren't any easy solution out there for bidirectional infinite scroll for React Native. Recently, while working on
v3.0.0 of React Native Chat SDK at Stream, we had to add bidirectional infinite scroll to our chat components. We had to jump through plenty of hurdles to make it happen while maintaining a good user experience around scrolling. Thus we decided to publish an excellent and small open-source package, to make this task easier for other React Native developers.
- GitHub github.com/GetStream/react-native-bidirectional-infinite-scroll/
- NPM npmjs.com/package/react-native-bidirectional-infinite-scroll
FlatList can be used like this:
What and How
This section will walk you through the hurdles of implementing bidirectional infinite scroll and how we solved them.
Support for onStartReached
FlatList from React Native has built-in support for infinite scroll in a single direction (from the end of the list). You can add a prop
FlatList. This function gets called when your scroll is near the end of the list, and thus you can append more items to the list from this function. You can Google for React Native infinite scrolling, and you will find plenty of examples for this. Unfortunately, the
FlatList doesn't provide any similar prop for
onStartReached for infinite scrolling in other directions.
We have added support for this prop as part of this package by simply adding the
onScroll handler on
FlatList, and executing the callback function (
onStartReached) when the scroll is near the start of the list. If you take a look at the implementation of VirtualizedList, you will notice that
onEndReachedfunction gets called only once per content length. That's there for a good purpose - to avoid redundant function calls on every scroll position change. Similar optimizations have been done for
onStartReached within this package.
Race condition between onStartReached and onEndReached
To maintain a smooth scrolling experience, we need to manage the execution order of
onEndReached. Because if both the callbacks happen at (almost) the same time, which means items will be added to the list from both directions, which may result in scroll jump - which is not a good UX. Thus it's essential to make sure one callback waits for the other callback to finish.
onStartReachedThreshold and onEndReachedThreshold
FlatList from React Native has a support for the prop
onEndReachedThreshold, which is documented here.
How far from the end (in units of visible length of the list) the bottom edge of the list must be from the end of the content to trigger the
Instead, it's easier to have a fixed value offset (distance from the end of the list) to trigger one of these callbacks. Thus we can maintain these two values within our implementation. So
onEndReachedThreshold props accept the number - distance from the end of the list to trigger one of these callbacks.
Smooth scrolling experience
FlatList from React Native accepts a prop - maintainVisibleContentPosition, which makes sure your scroll doesn't jump to the end of the list when more items are added to the list. But this prop is only supported on iOS for now. So taking some inspiration from this PR, we published our separate package to add support for this prop on Android - flat-list-mvcp. And thus
@stream-io/flat-list-mvcp is a dependency of the
Tutorial: Chat UI With Bidirectional Infinite Scroll
Now let's see how we can implement a chat message list, scrolling infinitely in both directions.
Lets start by creating a React Native app:
$ npx react-native init AwesomeChatList $ cd AwesomeChatList
Add the required dependencies:
$ yarn add react-native-bidirectional-infinite-scroll @stream-io/flat-list-mvcp
Next, run the app:
$ npx react-native run-ios
Note: The server will auto-refresh as you make changes to the code.
Create message list
Open this project in some editor (I love VS Code) and open
App.js in the project's root directory.
We are going to populate the list with dummy messages. In a real application, these messages are queried against a server. For example, we can write a simple utility function to mock this API call for querying
n number of messages.
Create a file -
Next, let's write a small UI component for the message bubble. Create a file named
Now let's first implement a simple list, which renders these messages on the first load. Copy the following content to
App.jsand hit save.
You should be able to see the list of messages as shown in the screenshot on the right.
Add Infinite Scroll
Next, let's implement infinite scroll to the list by adding
onEndReached prop functions.
onStartReached- add 10 messages at the beginning of the list
onEndReached- add 10 messages at the end of the list
Replace the contents of
App.js with the following:
And that's it. If you scroll up or down, you will see new messages being loaded in the list and scroll position being maintained as well (both for Android and iOS)
In real chat applications, you don't actually "infinitely" scroll. There is always an end to the
loadMoreRecentMessages function. And after this point, you will want the scroll to automatically move to the bottom of the list, as other users send a new message or if you send a new message.
Basically, after this point, we want to enable the "autoscroll to top" (bottom in our case, since the list is inverted) functionality of
FlatList. You can do this by setting a prop
true. Additionally, you can also set
Let's try to simulate this scenario by keeping a counter on the number of times recent messages were queried. Once the counter crosses 2, let's stop querying the message.
Let's add a "Send Message" button at the bottom to send a single message.
Replace the contents of
App.js with following
Now scroll to the bottom couple of times, until you can't load any more recent messages. Now try to send a single message by pressing the "Send Message" button. You will see scroll automatically scrolling to the bottom of the list. But if you scroll up a bit and then send a message - then the scroll position will be maintained. The
autoscrollToTopThreshold prop controls this threshold.
You've implemented a bidirectional infinite scroll with React Native! Additionally following props are available to add more customisations:
I hope you found it useful. Feel free to add some questions, comments, and feedback here.
