Stream Flutter: Building a Social Network with Flutter – Group Channels

9 min read
Nick P.
Nick P.
Published February 28, 2020 Updated March 2, 2020

In the third part of our series, we're building group chat into our social application. This allows users to chat with multiple people at the same time. We leverage Stream Chat to do the heavy lifting. This post assumes you've gone through part 1 and part 2.

Using our code from part 2, we only focus on the Flutter application, since our backend gives us everything we need already. To recap, the backend generates a frontend token for Stream Chat, which allows the Flutter application to communicate directly with the Stream Chat API. Also, since we have direct messaging implemented, there are no additional libraries. The previously installed Stream Chat Android and Swift libraries are all we need.

The app goes through these steps to enable group chat:

  • User navigates to a list of chat channels they can join. To start, there will be none, so they must create the first one.
  • The user hits "Create Chat Channel" and generates a chat channel with an id.
  • The mobile app queries the channel for previous messages and indicates to Stream that we'd like to watch this channel for new messages. The mobile app listens for new messages.
  • The user creates a new message and sends it to the Stream Chat API. Stream broadcasts this message to all users watching that channel.
  • When the message is broadcast, including messages created by the user, the mobile application consumes the event and displays the message.

We rely on Stream's Android/Swift libraries to do most of the work communicating with the API. This is done by leveraging Flutter's (Swift/Kotlin) Platform Channels to communicate with native code (Kotlin/Swift). If you'd like to follow along, make sure you get both the backend and mobile app running part 2 before continuing.

Prerequisites

Basic knowledge of Node.js (JavaScript), Flutter (Dart), and Kotlin, is required to follow this tutorial. Knowledge of Swift is useful if you want to browse the iOS implementation. This code is intended to run locally on your machine.

If you'd like to follow along, you'll need an account with Stream. Please make sure you can run a Flutter app, at least on Android. If you haven't done so, make sure you have Flutter installed. If you're having issues building this project, please check if you can create run a simple application by following the instructions here.

Once you have an account with Stream, you need to set up a development app (see part 1:

You'll need to add the credentials from the Stream app to the source code for it to work. See both the mobile and backend READMEs.

First, we'll explore how a user creates a group channel.

Step 1: Navigation

To start, we add a new navigation item to the bottom bar:

To do this, in main.dart we simply add a new BottomNavigationItem:

```dart
// mobile/lib/main.dart:120
BottomNavigationBarItem(
  icon: Icon(Icons.apps),
  title: Text('Channels'),
),

and the corresponding widget to boot when the user selects that item:

// mobile/lib/main.dart:70
if (_selectedIndex == 0) {
  // other nav item widgets
} else if (_selectedIndex == 3) {
  body = Channels(account: _account);
}

This boots the Channels widget that shows a list of channels and allows the user to create a new one.

Step 2: Creating a group channel

When the user first arrives at this screen, it will be empty if no one else has created any channels. We'll add a new channel button to the widget. Since this will be a list of group channels, we'll use a ListView with a single item, our new button, in it for now. We'll talk about how the FutureBuilder and RefreshIndicator with the _channel state in a bit. Here is the structural code with the "New Channel" button:

// mobile/lib/channels.dart:31
@override
Widget build(BuildContext context) {
  return FutureBuilder<List<dynamic>>(
    future: _channels,
    builder: (BuildContext context, AsyncSnapshot<List<dynamic>> snapshot) {
      if (!snapshot.hasData) {
        return Center(child: CircularProgressIndicator());
      }

      var tiles = [
        ListTile(
          title: Center(
            child: RaisedButton(
              child: Text("New Channel"),
              onPressed: () async {
                var channelCreated = await Navigator.push(
                  context,
                  MaterialPageRoute(builder: (_) => NewChannel(account: widget.account)),
                );

                if (channelCreated != null) {
                  _refreshChannels();
                }
              },
            ),
          ),
        )
      ];

      return RefreshIndicator(
        onRefresh: _refreshChannels,
        child: ListView(
          children: tiles,
        ),
      );
    },
  );
}

Our first list item is a button. When the user clicks the button, we navigate to a new widget called NewChannel. We check the return value of Navigator.push to check channel creation. If it were created, we'd refresh the channel list (we'll look at it in a bit).

Upon navigating, the user sees a form to create the channel. This is a simple widget where the user types in a channel id and creates the channel:

Let's look at the widget definition:

// mobile/lib/new_channel.dart:14
class _NewChannelState extends State<NewChannel> {
  final _channelIdController = TextEditingController();

  Future _createChannel(BuildContext context) async {
    if (_channelIdController.text.length > 0 && RegExp(r'^[a-zA-Z0-9]+$').hasMatch(_channelIdController.text)) {
      Navigator.pushReplacement(
          context,
          MaterialPageRoute(
            builder: (_) => LivestreamChat(account: widget.account, channelId: _channelIdController.text),
          ),
          result: true);
    } else {
      Scaffold.of(context).showSnackBar(
        SnackBar(
          content: Text('Please type a channel ID. It can only contain letters and numbers with no whitespace.'),
        ),
      );
    }
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(
        title: Text("Create New Channel"),
      ),
      body: Builder(
        builder: (context) {
          return Container(
            padding: EdgeInsets.all(12.0),
            child: Center(
              child: Column(
                children: [
                  TextField(
                    controller: _channelIdController,
                  ),
                  RaisedButton(
                    onPressed: () => _createChannel(context),
                    child: Text("Create Channel"),
                  ),
                ],
              ),
            ),
          );
        },
      ),
    );
  }
}

Here we see a simple Flutter form, backed with a TextEditingController. The first thing is to check is the text is a valid channel id. Stream Chat has rules around what a channel id can look like, and for simplicity, we'll just create and list channels by this id. You can refer to the docs if you'd like to add a separate channel name.

Once a user submits a channel id, we simply navigate to the LivestreamChannel widget. Notice we don't create a channel in Stream here. Stream lazily creates channels upon our first interaction with them. The LivestreamChannel will query and watch the channel, which will force its creation. Also, we use the name "Livestream" to mirror the type of channel we'll using in Stream. Livestream is the default channel type we want since, in part 4, we'll implement live video into our group channel. If none of the default types of work for your application, you can create your channel types.

Here is what the user sees when first joining a group channel:

This is the most complex widget, so we'll go through this in small chunks. Remember to refer to the source if you need to see the entire file. First, let's look at our build method to see how we're laying out our view:

// mobile/lib/livestream_channel.dart:136
@override
Widget build(BuildContext context) {
  return Scaffold(
    appBar: AppBar(
      title: Text(widget.channelId),
    ),
    body: Builder(
      builder: (context) {
        if (_messages == null) {
          return Center(child: CircularProgressIndicator());
        }

        return Column(
          children: [
            buildMessages(),
            buildInput(context),
          ],
        );
      },
    ),
  );
}

This is a simple scaffold that shows the id of the channel at the top and two pieces, the message list, and the new message input. When we initialize this widget, we listen to the channel, very similar to how we listened to direct message channels in part 2. We do this in the initState method:

// mobile/lib/livestream_channel.dart:20
@override
void initState() {
  super.initState();
  _setupChannel();
}

Future _setupChannel() async {
  cancelChannel = await ApiService().listenToChannel(widget.channelId, (messages) {
    setState(() {
      var prevMessages = [];
      if (_messages != null) {
        prevMessages = _messages;
      }
      _messages = prevMessages + messages;
    });
  });
}

We call the method .listenToChannel on the ApiService. This sets queries and watches the corresponding Stream channel. This means that it will give the initial set of messages and subsequent messages to us. Every time we receive messages, we merge them into the previously displayed set. We'll see how to display these messages in a few steps.

We also store a cancelChannel function which allows the widget to stop listening once it's disposed of:

// mobile/lib/livestream_channel.dart:38
@override
void dispose() {
  super.dispose();
  cancelChannel();
}

This is important. Otherwise, we'd have strange behavior due to orphaned listeners hanging around. Let's look at the implementation of .listenToChannel:

// mobile/lib/api_service.dart:79
Future<CancelListening> listenToChannel(String channelId, Listener listener) async {
  await platform.invokeMethod<String>('setupChannel', {'channelId': channelId});
  var subscription = EventChannel('io.getstream/events/$channelId').receiveBroadcastStream(nextListenerId++).listen(
    (results) {
      listener(json.decode(results));
    },
    cancelOnError: true,
  );

  return () {
    subscription.cancel();
  };
}

This is identical to how we set things up in part 3 except for the channel id. Since the user gives us an ID, we don't need to generate one. This method tells the native side to set up the channel with Stream and starts an EventChannel with that channel id. Once that's done, we subscribe to the EventChannel, which allows the native side to stream messages to us. We take that stream, listen to it, and parse any results that come across and pass them along to the widget.

Building your own app? Get early access to our Livestream or Video Calling API and launch in days!

Next, we go to our setupChannel implementation in Kotlin. This method coordinates with Stream, establishes a channel connection, and creates an event stream to send data back to the Flutter side:

// mobile/android/app/src/main/kotlin/io/getstream/flutter_the_stream/MainActivity.kt:209
private fun setupChannel(result: MethodChannel.Result, channelId: String) {
  val application = this.application
  var subId: Int? = null
  val client = StreamChat.getInstance(application)
  val channel = client.channel(ModelType.channel_livestream, channelId)
  val eventChannel = EventChannel(flutterView, "io.getstream/events/${channelId}")

  eventChannel.setStreamHandler(object : EventChannel.StreamHandler {
    override fun onListen(listener: Any, eventSink: EventChannel.EventSink) {
      channel.query(ChannelQueryRequest().withMessages(25).withWatch(), object : QueryChannelCallback {
        override fun onSuccess(response: ChannelState) {
          eventSink.success(ObjectMapper().writeValueAsString(response.messages))
        }

        override fun onError(errMsg: String, errCode: Int) {
          // handle errors
        }
      })

      subId = channel.addEventHandler(object : ChatChannelEventHandler() {
        override fun onMessageNew(event: Event) {
          eventSink.success(ObjectMapper().writeValueAsString(listOf(event.message)))
        }
      })
    }

    override fun onCancel(listener: Any) {
      channel.stopWatching(object : CompletableCallback {
        override fun onSuccess(response: CompletableResponse?) {
        }

        override fun onError(errMsg: String, errCode: Int) {
          // handle errors
        }
      })
      channel.removeEventHandler(subId)
      eventChannels.remove(channelId)
    }
  })

  eventChannels[channelId] = eventChannel

  result.success(channelId)
}

This code is what communicates with Stream. First, we create a Channel object with the type livestream and our channel id. As described before, livestream is the appropriate default channel type for our group chat. It allows any user to join the channel and chat with others.

Next, we start a Flutter EventChannel in Kotlin. This allows us to stream data back to the Flutter side. In our .onListen method, which is called when the Flutter side subscribes to the EventChannel, we query the channel for the initial set of messages and tell Stream to watch for future messages. This initial query will create the channel in Stream if it doesn't exist. The initial set of messages will trigger our QueryChannelCallback, and they've sent over the EventChannel as a JSON string.

To receive future messages, we need to register an event handler with the channel. This is done by calling channel.addEventHandler. Since we indicated we'd like to watch the channel when we did our initial query, any future messages will be sent to our ChatChannelEventHandler callback. We send these over the EventChannel as a JSON string, just like above.

When the Flutter side indicates they'd like to cancel, the .onCancel is called. We simply stop watching and clean up our event handlers. Now the user is ready to send their first message.

Step 3: Sending a message

First, we'll need an input and submit button:

// mobile/lib/livestream_channel.dart:95
Widget buildInput(BuildContext context) {
  return Container(
    margin: EdgeInsets.only(bottom: MediaQuery.of(context).padding.bottom),
    child: Row(
      children: <Widget>[
        // Edit text
        Flexible(
          child: Container(
            padding: EdgeInsets.symmetric(horizontal: 8.0),
            child: TextField(
              style: TextStyle(fontSize: 15.0),
              controller: _messageController,
              decoration: InputDecoration.collapsed(
                hintText: 'Type your message...',
                hintStyle: TextStyle(color: Colors.grey),
              ),
            ),
          ),
        ),

        // Button send message
        Material(
          child: Container(
            margin: EdgeInsets.symmetric(horizontal: 8.0),
            child: IconButton(
              icon: Icon(Icons.send),
              onPressed: _sendMessage,
            ),
          ),
          color: Colors.white,
        ),
      ],
    ),
    width: double.infinity,
    height: 50.0,
    decoration:
        BoxDecoration(border: Border(top: BorderSide(color: Colors.blueGrey, width: 0.5)), color: Colors.white),
  );
}

This looks hairy, but all that's happening is a simple, flexible layout with two elements, an input box and a submit. The submit button is the size of the icon, and the text input is adjustable, which allows it to take up the remaining space. We also wrap it in a Container with some margin to avoid phone-specific features that take up bottom real estate, such as the home indicator on iOS.

When the user has typed a message and hit submit, we're ready to send the message to the Stream channel. Here's the implementation of _sendMessage:

// mobile/lib/livestream_channel.dart:44
Future _sendMessage() async {
  if (_messageController.text.length > 0) {
    await ApiService().postChannelMessage(widget.channelId, _messageController.text);
    _messageController.clear();
  }
}

This checks the length and passes it along to the API method .postChannelMessage:

// mobile/lib/api_service.dart:74
Future<bool> sendChannelMessage(String channelId, String message) async {
  await platform.invokeMethod('postChannelMessage', {'channelId': channelId, 'message': message});
  return true;
}

Which then passes it to the Kotlin method .postChannelMessage:

// mobile/android/app/src/main/kotlin/io/getstream/flutter_the_stream/MainActivity.kt:276
private fun postChannelMessage(result: MethodChannel.Result, channelId: String, message: String) {
  val client = StreamChat.getInstance(this.application)
  val channel = client.channel(ModelType.channel_livestream, channelId)
  val streamMessage = Message()
  streamMessage.text = message
  channel.sendMessage(streamMessage, object : MessageCallback {
    override fun onSuccess(response: MessageResponse?) {
      result.success(true)
    }

    override fun onError(errMsg: String?, errCode: Int) {
      // handle errors
    }
  })
}

Here we create a Stream Message and send it to the channel. There's not a lot for our code to do since Stream's libraries take care of the work. We simply return true when Stream indicates success via our callback.

Step 4: Viewing messages

We're finally ready to view all our hard work. Since we're already listening to the channel, which was set up in part 2, all we need to do is display the messages. We create a list view that takes up the rest of the space not taken by our create message input:

// mobile/lib/livestream_channel.dart:51
Widget buildMessages() {
  return Flexible(
    child: ListView(
      padding: EdgeInsets.all(10.0),
      reverse: true,
      children: _messages.reversed.map<Widget>(buildMessage).toList(),
    ),
  );
}

Widget buildMessage(dynamic message) {
  var isMyMessage = message['userId'] == widget.account['user'];
  return Row(
    mainAxisAlignment: isMyMessage ? MainAxisAlignment.end : MainAxisAlignment.start,
    children: [
      Column(
        crossAxisAlignment: CrossAxisAlignment.start,
        children: <Widget>[
          Container(
            child: Text(
              message['text'],
              style: TextStyle(color: isMyMessage ? Colors.white : Colors.black),
            ),
            padding: EdgeInsets.fromLTRB(15.0, 10.0, 15.0, 10.0),
            width: 200.0,
            decoration: BoxDecoration(
                color: isMyMessage ? Colors.blueAccent : Colors.black12, borderRadius: BorderRadius.circular(8.0)),
            margin: EdgeInsets.only(right: 10.0),
          ),
          Container(
            margin: EdgeInsets.only(left: 15.0, top: 5.0, bottom: 10.0),
            child: isMyMessage
                ? null
                : Text(
                    message['userId'],
                    style: TextStyle(color: Colors.black54, fontSize: 10.0),
                  ),
          ),
        ],
      )
    ],
  );
}

This creates iOS message style bubbles with our messages on the right in blue and other user's messages on the left in grey with their name attached to the message. We reverse the list, so the most recent messages are on the bottom:

Step 5: Viewing other channels

Now a user can go back to the channel list and view all the channels, including those created by other users. Let's revisit the widget we started in Step 1 and update it, so it queries and displays the list of channels:

All that's left to get this widget fully functional is plugging in the calls to ApiService.channels and adding those to our list view. First, when we first boot the widget in initState, we need to load the channels:

// mobile/lib/channels.dart:19
@override
void initState() {
  super.initState();
  _channels = ApiService().channels();
}

The ApiService.channel call simple calls to do the native side and decodes the result:

// mobile/lib/api_service.dart:35
Future<List<dynamic>> channels() async {
  var result = await platform.invokeMethod<String>('getChannels', {});
  return json.decode(result);
}

The native implementation to retrieve channels is a similar pattern to how we query for messages above:

// mobile/android/app/src/main/kotlin/io/getstream/flutter_the_stream/MainActivity.kt:150
private fun getChannels(result: MethodChannel.Result) {
  val client = StreamChat.getInstance(application)
  client.queryChannels(QueryChannelsRequest(FilterObject(hashMapOf("type" to ModelType.channel_livestream)), QuerySort()), object : QueryChannelListCallback {
    override fun onSuccess(response: QueryChannelsResponse) {
      result.success(ObjectMapper().writeValueAsString(response.channels.map { it.id }))
    }

    override fun onError(errMsg: String?, errCode: Int) {
      // handle errors
    }
  })
}

We ask the Stream library to query all livestream channels. We only look for the livestream, so we don't list the private direct messaging channels. Once the library has returned this data to us, we pass it along as a JSON string to the Flutter side.

Since our ApiService is returning a Future that will contain channels, we plug this Future into a FutureBuilder to deal with the state changes:

// mobile/lib/channels.dart:31
@override
Widget build(BuildContext context) {
  return FutureBuilder<List<dynamic>>(
    future: _channels,
    builder: (BuildContext context, AsyncSnapshot<List<dynamic>> snapshot) {
       // ...
    }
  );
}

Once that data loads, we can use the snapshot.data from the FutureBuilder to add to our ListView inside our .build method:

// mobile/lib/channels.dart:62
tiles.addAll(
  snapshot.data
      .map((channel) => ListTile(
            title: Text(channel),
            onTap: () {
              Navigator.push(
                context,
                MaterialPageRoute(
                  builder: (_) => LivestreamChat(account: widget.account, channelId: channel),
                ),
              );
            },
          ))
      .toList(),
);

When we click on a ListTile, we simply navigate to the appropriate LivestreamChat widget. Now a user will see all channels and be able to chat in any of them.

The last remaining piece is to plug in the ApiService.channels call in where we need to refresh the list. The RefreshIndicator calls the method _refreshChannels when a user pulls to refresh. We also call this when we create a channel successfully. Here's the implementation of _refreshChannels:

// mobile/lib/channels.dart:25
Future _refreshChannels() async {
  setState(() {
    _channels = ApiService().channels();
  });
}

This method simply sets the state to a new Future that will complete with the latest list of channels. Once that ends, we'll see the updated list.

That's it! We now have a fully functioning group chat via Stream Channels!

In addition to the tutorial above, Stream offers a comprehensive Flutter SDK Tutorial, so you can see how to get up and running quickly with Flutter.

Integrating Video With Your App?
We've built a Video and Audio solution just for you. Check out our APIs and SDKs.
Learn more ->
