Screen Sharing

Screen Sharing​

Our Video SDK provides an easy ways to enable screensharing in your application. In the following examples, we would learn to control and configure screen sharing.

Start/Stop Screen Sharing​

await call.screenShare.toggle();

// or
await call.screenShare.enable();
await call.screenShare.disable();

// alternatively
import { useCallStateHooks } from '@stream-io/video-react-sdk';

const { useScreenShareState } = useCallStateHooks();
const { screenShare } = useScreenShareState();
await screenShare.toggle();

Screen Sharing Status​

Here is how you can access the status of screen sharing:

import { useCallStateHooks } from '@stream-io/video-react-sdk';

call.screenShare.state.status; // enabled, disabled or undefined

// or, if you want to subscribe to changes
const { useScreenShareState } = useCallStateHooks();
const { status } = useScreenShareState();

console.log('Screen sharing is:', status === 'enabled' ? 'active' : 'inactive');

Screen Sharing Settings​

The behavior of the screen share video track can be customized, and a few parameters can be set:

call.screenShare.setSettings({
  maxFramerate: 15, // will be clamped between 1 and 15 fps
  maxBitrate: 1500000, // will use at most 1.5Mbps
});

await call.screenShare.enable();

Render Screen Share​

Our SDK provided ParticipantView component can automatically render the screen share video track.

Screen Share Audio​

Start/Stop Screen Share Audio​

// enable it
call.screenShare.enableScreenShareAudio();

// publish video and audio (if available, and supported by the browser)
await call.screenShare.enable();

// disable it
call.screenShare.disableScreenShareAudio();

Play Screen Share Audio​

Our SDK provided ParticipantView component can automatically play the screen share audio track.

Caveats​

Screen Share Audio has limited support across browsers and platforms. For most up-to-date information, please take a look at Browser Compatibility.

In addition to that, there are a few caveats that you should be aware of:

  • On Windows, the entire system audio can be captured, but on MacOS and Linux, only the audio of a tab can be captured.
